| Deepal S05 | Deepal S05 2024 200Max Extended Range Edition | Deep Blue S05 2024 200Ultra Extended Range Edition |
| Basic Information | ||
| Manufacturer | Deepal | Deepal |
| level | Compact SUV | Compact SUV |
| Energy Type | Extended Range | Extended Range |
| Availability | 2024.10 | 2024.10 |
| Electric Motor | Extended range 218 horsepower | Extended range 218 horsepower |
| Pure electric range (km) Ministry of Industry and Information Technology | 155 | 155 |
| Pure electric range (km) WLTC | 155 | 155 |
| Pure electric range (km) CLTC | 200 | 200 |
| Comprehensive cruising range (km) Ministry of Industry and Information Technology | 1234 | 1234 |
| Charging time (hours) | Fast charge 0.33 hours | Fast charge 0.33 hours |
| Fast charging capacity (%) | 30-80 | 30-80 |
| Maximum power (kW) | 160(218Ps) | 160(218Ps) |
| Maximum torque (N·m) | 320 | 320 |
| Gearbox | Electric vehicle single speed gearbox | Electric vehicle single speed gearbox |
| Length x width x height (mm) | 4620x1900x1600 | 4620x1900x1600 |
| Body structure | 5-door 5-seater SUV | 5-door 5-seater SUV |
| Maximum speed (km/h) | 175 | 175 |
| Official 0-100km/h acceleration time (s) | 7.9 | 7.9 |
| WLTC comprehensive fuel consumption (L/100km) | 0.81 | 0.81 |
| Power consumption per 100 kilometers (kWh/100km) | 16.6kWh | 16.6kWh |
| Electric energy equivalent fuel consumption (L/100km) | 1.88 | 1.88 |
| Body | ||
| Wheelbase(mm) | 2880 | 2880 |
| Front wheel track (mm) | 1625 | 1625 |
| Rear wheelbase(mm) | 1640 | 1640 |
| Body structure | SUV | SUV |
| Number of doors | 5 | 5 |
| Door opening method | Swing door | Swing door |
| Number of seats | 5 | 5 |
| Curb weight(kg) | 1835 | 1835 |
| Full load mass (kg) | 2210 | 2210 |
| Fuel tank capacity (L) | 45 | 45 |
| Front luggage compartment volume (L) | ||
| Luggage compartment volume (L) | 464 | 464 |
| engine | ||
| Engine Model | JL469Q1 | JL469Q1 |
| Displacement (mL) | 1497 | 1497 |
| Displacement(L) | 1.5 | 1.5 |
| Air intake form | Naturally Aspirated | Naturally Aspirated |
| Engine layout | Sideways | Sideways |
| Cylinder arrangement | L | L |
| Number of cylinders | 4 | 4 |
| Number of valves per cylinder | 4 | 4 |
| Valve mechanism | DOHC | DOHC |
| Maximum horsepower (Ps) | 98 | 98 |
| Maximum power (kW) | 72 | 72 |
| Maximum net engine power (kW) | 70 | 70 |
| Fuel form | Extended Range | Extended Range |
| Fuel grade | 92# | 92# |
| Oil supply method | Multi-point EFI | Multi-point EFI |
| Cylinder head material | Aluminum Alloy | Aluminum Alloy |
| Cylinder material | Aluminum Alloy | Aluminum Alloy |
| Environmental standards | China VI | China VI |
| Electric Motor | ||
| Motor Description | Extended range 218 horsepower | Extended range 218 horsepower |
| Motor Type | Permanent magnet/synchronous | Permanent magnet/synchronous |
| Total motor power (kW) | 160 | 160 |
| Total motor horsepower (Ps) | 218 | 218 |
| Total torque of the motor (N·m) | 320 | 320 |
| Maximum power of rear motor (kW) | 160 | 160 |
| Maximum torque of rear motor (N·m) | 320 | 320 |
| Number of drive motors | Single motor | Single motor |
| Motor layout | Post | Post |
| Battery/Charging | ||
| Battery Type | Lithium iron phosphate battery | Lithium iron phosphate battery |
| Battery brand | CATL | CATL |
| Battery capacity (kWh) | 27.28 | 27.28 |
| Battery Charging | Fast charge 0.33 hours | Fast charge 0.33 hours |
| ●Fast charging port | ●Fast charging port | |
| Fast charging port location | Right fuel tank | Right fuel tank |
| Slow charging port location | Right fuel tank | Right fuel tank |
| Battery Temperature Management System | ●Low temperature heating | ●Low temperature heating |
| ●Liquid Cooling | ●Liquid Cooling | |
| VTOL mobile power station function | ●Standard | ●Standard |
| VTOL maximum external discharge power | 6kW | 6kW |
| Gearbox | ||
| Gearbox Description | Electric vehicle single speed gearbox | Electric vehicle single speed gearbox |
| Number of gears | 1 | 1 |
| Gearbox Type | Fixed gear ratio gearbox | Fixed gear ratio gearbox |
| Chassis/Steering | ||
| Drive mode | Rear-engine, rear-wheel drive | Rear-engine, rear-wheel drive |
| Front suspension type | McPherson independent suspension | McPherson independent suspension |
| Rear suspension type | Multi-link independent suspension | Multi-link independent suspension |
| Steering type | Electric power assist | Electric power assist |
| Vehicle structure | Load-bearing | Load-bearing |
| Wheels/Brakes | ||
| Front brake type | Ventilated disc | Ventilated disc |
| Rear brake type | Solid disc | Solid disc |
| Parking brake type | Electronic parking brake | Electronic parking brake |
| Front tire size | 225/60 R18 | 225/60 R18 |
| Rear tire size | 225/60 R18 | 225/60 R18 |
