1 / 77 source photos · Select a thumbnail to view. Photos may show different colors or configurations.
Ready stock records
AION V 2026 Tyrannosaurus Family Edition 520 Zhihao Edition
Original listed vehicle price14640
Historical listing value. Confirm currency, current export price, options and delivery terms with your quotation.
Original price information
- Original listed price: 14640
Source values retained for reference. Zero or placeholder values are not a selling price.
- Transmission
- Single-Speed (Fixed Gear Ratio)
Vehicle specification, options and delivery terms are confirmed with your quotation.
About this vehicle
Vehicle overview
Configuration details
Full original configuration
Complete source tables retained. Scroll across for multi-edition tables; confirm the exact edition with your quotation.
| Basic Parameters | |
| Model Name | AION V 2026 Tyrannosaurus Family Edition 520 Zhihao Edition |
| Manufacturer | GAC Aion |
| Class | Compact SUV |
| Energy Type | Battery Electric (BEV) |
| Emission Standard | — |
| Body Type | 5-Door 5-Seat SUV |
| Length x Width x Height (mm) | 4580×1854×1639 |
| Wheelbase (mm) | 2775 |
| Front / Rear Track (mm) | 1600 / 1600 |
| Doors / Seats | 5 / 5 |
| Cargo Volume (L) | 427 |
| Drag Coefficient (Cd) | 0.273 |
| Top Speed (km/h) | 160 |
| 0-100 km/h Acceleration (s)—0-100 km/h Acceleration (s) | 7.9 |
| Fuel Equivalent (L/100km) | 1.27 |
| Curb Weight (kg) | 1780 |
| Gross Vehicle Weight (kg) | 2280 |
| Electric Motor | |
| Front Motor Brand | Ruipai Power (Inovance) |
| Front Motor Model | TZ180XYXOF51 |
| Motor Type | Permanent Magnet / Synchronous |
| Number of Drive Motors | Single Motor |
| Motor Layout | Front-Mounted |
| Drivetrain | Front-Engine, Front-Wheel Drive (FF) |
| Total Motor Power (kW) | 150 |
| Total Motor Power (Ps) | 204 |
| Total Motor Torque (N·m) | 205 |
| Transmission | Single-Speed (Fixed Gear Ratio) |
| Battery / Charging | |
| Battery Type | LFP (Ammo Battery 2.0) |
| Battery Brand | CALB / Yinpai / Shidai GAC (Ammo Battery 2.0) |
| Battery Capacity (kWh) | 62.27 kWh (62.2/62.7 kWh, Yinpai Battery) |
| CLTC Range (km) | 520 |
| Power Consumption (kWh/100km) | 12.8 |
| Fast Charging | ● (400V / 3C Fast Charging) |
| Fast Charge Time (30%-80%)—80%) | Approx. 22—-25 min (0.37 h) |
| Battery Cooling | Liquid Cooling |
| Battery Low-Temperature Heating | ● (Integrated Heat Pump System) |
| External Discharge (V2L) | ● (Max 3.3 kW) |
| Chassis & Steering | |
| Front Suspension | MacPherson Strut (Independent) |
| Rear Suspension | Multi-Link (Independent) |
| Steering Assist | Electric Power Steering |
| Body Structure | Unibody |
| Auto Hold | ● |
| Hill-Start Assist | ● |
| Hill Descent Control | ● |
| Wheels & Brakes | |
| Front / Rear Brakes | Ventilated Disc / Disc |
| Parking Brake | Electronic Parking Brake |
| Front / Rear Tire Size | 215/55 R18 |
| Wheel Material | Aluminum Alloy |
| Spare Tire | Tire Repair Kit (Optional Non-Full-Size) |
| Safety Features | |
| Driver / Passenger Airbags | ● / ● |
| Front Side Airbags | ● |
| Front & Rear Curtain Airbags | ● / ● |
| Knee Airbag | ● |
| Center Airbag | — |
| Tire Pressure Monitoring | ● (Tire Pressure Display) |
| Seatbelt Unfastened Reminder | ● (Front Row) |
| ISOFIX Child Seat Anchors | ● |
| ABS Antilock | ● |
| Brake Force Distribution (EBD) | ● |
| Brake Assist (EBA) | ● |
| Traction Control (ASR) | ● |
| Stability Control (ESC) | ● |
| Pedestrian Protection | — |
| Low-Speed Moving Warning | ● |
| Built-in Dashcam | ● (Front-Facing Camera Recording) |
| Driving Assistance / Handling | |
| Driving Assistance Level | L2 (GAC GSD Intelligent Driving) |
| Cruise Control | ● |
| Full-Speed Adaptive Cruise (ACC) | ● |
| Lane Departure Warning | ● |
| Lane Keeping Assist | ● |
| Lane Centering | ● |
| Traffic Sign Recognition | ● |
| Automatic Emergency Braking | ● |
| Front Collision Warning | ● |
| Front Cross-Traffic Alert (FCTA) | — |
| Rear Collision Warning (RCW) | — |
| Rear Cross-Traffic Alert (RCTA) | — |
| Blind Spot Detection (BSD) | — |
| Door Open Warning (DOW) | — |
| Driver Fatigue Alert / DMS | — |
| Drive Mode Selection | Sport / Eco / Standard Comfort |
| Energy Recovery System | ● |
| Front / Rear Parking Sensors | Front — / Rear ● |
| Reversing Image | ● |
| 360° Surround View | ● |
| Transparent Chassis / 540° View | ● |
| Highway Navigation Driving Assist (NDA) | — |
| Automatic Lane Change (ILC) | — |
| Automatic Parking | ● (Basic Automatic Parking) |
| Remote Vehicle Move | — |
| Memory Parking | — |
| Sentry Mode / Remote View | ● |
| Roadside Assistance Call | ● |
| ADAS Computing Chip | Rockchip RK3588 (Infotainment AI Chip) |
| LiDAR | — |
| Millimeter-Wave Radar Count | 1 |
| Ultrasonic Sensor Count | 3-6 (Including Automatic Parking) |
| Exterior Camera Count | 5 |
| Exterior / Anti-theft | |
| Sunroof Type | ● (Panoramic Roof, Fixed) |
| Aluminum Alloy Wheels | ● |
| Flush Door Handles | ● |
| Central Door Locking | ● |
| Remote Key | ● |
| Keyless Start | ● |
| Keyless Entry | ● (Front Row) |
| Bluetooth Virtual Key (Mobile) | — |
| Power Tailgate | ● |
| Hands-Free Tailgate | ● |
| Power Tailgate Position Memory | ● |
| Remote Engine Start | ● |
| Factory-Fitted ETC Device | — |
| Interior / Steering Wheel | |
| Steering Wheel Material | Leather |
| Steering Wheel Adjustment | Tilt and Telescopic Adjustment |
| Multifunction Steering Wheel | ● |
| Heated Steering Wheel | — |
| Steering Wheel Memory | — |
| Gear Shift Type | Electronic Column Shifter |
| Trip Computer Display | ● |
| Digital Instrument Cluster Size | 8.88 in. (Full LCD) |
| Head-Up Display (HUD) | — |
| Seats | |
| Seat Material | Synthetic Leather (Premium Leather Seats) |
| Driver Seat Adjustment | Fore/Aft, Backrest, Height Adjustment |
| Passenger Seat Adjustment | Fore/Aft, Backrest Adjustment |
| Driver / Passenger Power Adjustment | ● / ● |
| Driver / Passenger Seat Heating | Front — / Rear — |
| Front Seat Ventilation | — |
| Front Seat Massage | — |
| Power Seat Memory | — |
| Second-Row Backrest Angle Adjustment | ● (Max 137°) |
| Rear Seat Folding | 40:60 Split-Folding |
| Front / Rear Center Armrest | ● / ● |
| Rear Cup Holder | ● |
| Second-Row Fold-Out Table | — |
| Rear Seat Heating | — |
| Rear Center Headrest | ● |
| Lighting | |
| Low Beam | LED |
| High Beam | LED |
| Daytime Running Lights | ● |
| Front Halo Light | ● |
| Automatic Headlights | ● |
| Adaptive High Beams (IHBC) | ● |
| Cornering Lights | — |
| Front Fog Lights | — |
| Headlight Height Adjustment | ● |
| Follow-Me-Home Headlights | ● |
| Glass / Mirrors | |
| Front / Rear Power Windows | ● / ● |
| One-Touch Power Windows | ● (All Windows) |
| Anti-Pinch Windows | ● |
| Front Multi-Layer Acoustic Glass | — |
| Green Glass (Heat / Privacy Insulation) | ● (Front / Rear Windshield + Four Doors) |
| Exterior Mirror Functions | Power Adjustment, Heating, Power Folding, Auto-Fold on Lock |
| Interior Mirror Functions | Manual Anti-Glare |
| Vanity Mirror with Sunshade | ● (Driver / Passenger with Illumination) |
| Rear Wiper | ● |
| Rain-Sensing Wipers | ● (Rain Sensor) |
| Smart Connectivity / Multimedia | |
| Center Display Size | 14.6 in. (Floating Touchscreen) |
| Infotainment System | ADiGO 6.0 (AI Voice Large Model) |
| Satellite Navigation | ● |
| Real-Time Traffic Display | ● |
| Mobile Connectivity / Mapping | Huawei HiCar / CarLink |
| Connected Services | ● |
| 4G / 5G Network | 4G |
| OTA Updates | ●（FOTA） |
| Wi-Fi Hotspot | ● |
| Voice Recognition Control | ● (Four-Zone Recognition, Continuous Wake-Free Dialogue) |
| Bluetooth / In-Car Telephone | ● |
| USB / Type-C Ports | USB + Type-C (Front / Rear) |
| Wireless Phone Charging | — |
| Number of Speakers | 9 Speakers |
| Mobile App Remote Control | ● |
| Climate / Comfort | |
| Climate Control Type | Automatic Climate Control |
| Heat Pump | ● (18-in-1 Integrated Heat Pump) |
| Rear Air Vents | ● |
| Dual-Zone Climate Control | ● (Dual-Zone) |
| Cabin PM2.5 Filtration | ● |
| In-Car Air Purifier | ● (Negative Ion Generator) |
| Cabin Ambient Lighting | — |
| Vanity Mirror Illumination | ● |
| Remarks | |
| Exterior Colors | Polar White, Night Shadow Black, Starry Blue, Sea Glow Gray, Holographic Silver, Warm Velvet Gold (Subject to Official) |
Grouped specifications
Vehicle specifications
Choose a section, then select its heading to expand. All source values remain available.
Organized original source values, not manufacturer verification. Multiple values may describe different editions; confirm the exact trim before quotation.
Vehicle identity
- Body type
- SUV
- 5-Door 5-Seat SUV
- Unibody
- Color
- Multiple colors
- Brand
- GAC Aion
- Vehicle class
- Compact SUV
Source information · needs review · 3 original source entries · Multiple original values retained · Different source wording or units; verify before publishing
Source information · needs review
Source information · needs review
Source information · needs review
Dimensions & space
- Overall dimensions
- 4580×1854×1639 mm
- Wheelbase
- 2775 mm
- Cargo volume
- 427 L
Source information · needs review
Source information · needs review
Source information · needs review
Powertrain
- Engine
- Permanent Magnet / Synchronous
- Drive type
- Front-Engine, Front-Wheel Drive (FF)
- Motor power
- 150 kW
- 204 Ps
- Transmission
- Single-Speed (Fixed Gear Ratio)
Source information · needs review
Source information · needs review
Source information · needs review · 2 original source entries · Multiple original values retained · Different source wording or units; verify before publishing
Source information · needs review
Battery, range & charging
- Energy / fuel type
- BEV
- Battery Electric (BEV)
- Emission standard as listed
- —
- Battery type
- LFP (Ammo Battery 2.0)
- Battery capacity
- 62.27 kWh (62.2/62.7 kWh, Yinpai Battery) kWh
- CLTC range
- 520 km
Source information · needs review · 2 original source entries · Multiple original values retained · Different source wording or units; verify before publishing
Source information · needs review
Source information · needs review
Source information · needs review
Source information · needs review
Chassis & performance
- Top speed
- 160 km/h
- Curb weight
- 1780 kg
- Gross vehicle weight
- 2280 kg
- Front suspension
- MacPherson Strut (Independent)
- Rear suspension
- Multi-Link (Independent)
Source information · needs review
Source information · needs review
Source information · needs review
Source information · needs review
Source information · needs review
Safety & comfort equipment
- Original equipment description
- FWD
Source information · needs review
